Model of Roman Catapult Constructed by the Author.

Weight 1 1/2 tons Range, with 6-lb. stone ball, 300 yards
1. Twisting up the skein of cord by means of the winches. 2. Winding down the arm. 3. Releasing the arm when fully wound down.
